Four caster wheels follow ground contours
By having four caster wheels per deck, the FM4012 Mower follows ground contours with ease. Tubular caster wheel arms are bolted to rail supports for added durability.
Front-mounted roller shown
Rear-mounted roller shown
In option, each deck on the FM4012 can received up to three anti-scalping rollers specific for highly uneven terrain.
Deck baffling around the blade ensures optimum cut quality
The FM4012 deck depth with baffling around the blades ensures exceptional material distribution and a higher quality of cut.
6-year gearbox warranty
Each of the FM4012 gearboxes include a 6-year warranty.
Wing deck lift cylinder
The FM4012 has hydraulic lifts for the wing and rear decks to automatically lock them in the up position for transport. The lift and lower for the wings and deck are operated together through the same hydraulic supply with single acting cylinder, requiring only 1 tractor rear SCV.
Optional hydraulic release
To unfold the wings and rear deck from transport position to working position, the FM4012 has a standard rope-pull latch release. An optional hydraulic-wings latch release kit allows the operator to release the decks from transport lock position using a 2nd rear SCV.
FM4012 Sheaves & spindle
For longer belt life, FM4012 comes with cast iron blade sheaves, and also includes ductile iron spindles that have a 1-year warranty and are lubed for life.
The FM4012 has a transport width of 2.31 m (7.58 ft), height of 1.82m (5.96 ft) and length of 3.43m (11.25 ft) to fit in standard size garage.
Mower blades
High blade-tip speed and precise blade overlap work together to ensure exceptional, performance, and cut quality. With a speed of 91.44 m/s (18,000 fpm) blade tip speeds, the cut quality stays intact at mowing speeds up to 8 km/h (5 mph).
Easy shield removal
The shields, protecting the drive belt, are easy to remove without the need of a tool. This ensures easy access to the sheaves, belt, and spring-loaded idler.
Rear chains
Rear chain shields are optional.
This optional hydraulic wing latch release kit is available for the FM4012.
| Key Specs | fm40-flex-wing Current Model |
|---|---|
| Cutting width - Total | 3.65 m 12 ft |
| Transport width | 2.4 m 7.75 ft |
| Cutting height- Range, in. (cm) | 3.8-11.4 cm 1.5-4.5 in. |
| Deck - Thickness, gauge | 10 gauge 3.416 mm 0.1345 in. |
| Discharge type | Rear |
| Caster wheels - Type | Solid |
| Hitch - Adjustment | Self-leveling, multi-position |
| Hitch - Drawbar | Category 1 |
| Power | 18.6-44.7 kW 25-60 hp |
| PTO speed rpm | 540 rpm |
| Cutting width | |
| Total | 3.8 m 12.5 ft |
| Center deck | 1.4 m 4.5 ft |
| Wing deck | 1.4 m 4.5 ft |
| Dimensions | |
| Transport width | 2.4 m 7.75 ft |
| Overall width | 3.8 m 12.583 ft |
| Transport length | 3.2 m 10.5 ft |
| Max overall length | 3.4 m 11.25 ft |
| Transport height | 1.8 m 5.9 ft |
| Transport Dimensions (LxWxH): | |
| Working Length | |
| Working width | |
| Weight | |
| Operating | 923.1 kg 2,035 lb |
| Shipping | 950.3 kg 2,095 lb |
| Operating tongue | 145.1 kg 320 lb |
| Transport tongue | 231.3 kg 510 lb |
| Tractor requirements | |
| Power | 18.6-44.7 kW 25-60 hp |
| PTO speed rpm | 540 rpm |
| Engine HP Requirements | |
| PTO hp Range | |
| Gearbox | |
| Ratio | 1-to-2.5 |
| Splitter gearbox | 74.6 kW 100 hp |
| Mower deck gearbox | 26.1 kW 35 hp |
| Drive | |
| Type | Gearbox over V-belt |
| Wing driveline | Category 3 |
| Input driveline | Category 3 CV |
| Hitch | |
| Drawbar | Category 1 |
| Clevis | Floating |
| Adjustment | Self-leveling, multi-position |
| Category (Drawbar) | |
| Type | |
| iMatch / Quick hitch | |
| Deck | |
| Thickness, gauge | 10 gauge 3.416 mm 0.1345 in. |
| Overlap | 15.2 cm 6 in. |
| Lift cylinders | 7.6x25.4 cm 3x10 in. |
| Wing travel, degrees | Up 20 degree (angle) and down 15 degree (angle) |
| Discharge type | Rear |
| Cutting height | |
| Range, in. (cm) | 2.5-11.4 cm 1-4.5 in. |
| Adjustment | |
| Blade | |
| Average tip speed | 4,938 m/min 16,200 fpm |
| Spindle quantity | Nine |
| Spindle type | Cast iron |
| Spindle bearings | Greaseable ball |
| Overlap | 3.8 cm 1.5 in. |
| Dimensions, type 1 | 0.6x6.4 cm 0.25x2.5 in. |
| Composition | Heat-treated alloy steel |
| Blade Spindles | |
| Blade Tip Speed | |
| Dimensions, type 2 | |
| Number of Blades | |
| Tires | |
| Transport | (2) 20X8-10 |
| Transport Wheels | |
| Caster wheels | |
| Quantity | 10 |
| Type | Solid |
| Size | 25.4x10.2 cm 10x4 in. |
| Bearings | Powder metal bushing |
| Rollers | |
| Front | Standard |
| Front and Rear Anti-Scalping Roller | |
| Ground pressure | |
| Pounds per square inch (kg per square centimeter) | 5 pounds per square inch |
| Belts | |
| Adjustment | Spring-loaded idler |
| Adjustments: Spring-loaded idler | |
| Type | |
| Construction | |
| Mainframe | 10.2 cm 4 in. |
| Lighting and safety | |
| Transport lights | Standard |
| Rear chain shields | Standard |
| Auto-engage transport latch | Standard |
| Markings | Slow-moving vehicle |
| Hydraulic Wing Latch Release Kit | |
| Set-up time | |
| Labor hours | 1.25 |
| Warranty | |
| Machine | 1 year |
| Gearbox | 1 year |
| Spindle |
