The 1023E and 1025R Tractors feature a HST.
Twin Touch foot controls allow selecting both speed and direction of travel with a touch of the toe. Ideally suited for jobs where productivity is a must, such as loader or mower applications.
Transmission has two speeds - Hi and Lo range.
Durability features include:
The 1025R operator's station has been designed to allow greater operator comfort and increased visibility. Large and easy to grab handrails are located on each fender for an easier on and off of the tractor from either side.
*Features shown are available with all current model year tractors.
Foldable Roll-Gard™ rollover protective structure (ROPS) and retractable-seat belt are standard equipment to protect the operator in the event of a tractor tip-over, as well as improve the ability to store tractor in a garage.
Seat belt is within easy reach of the operator, to encourage the use of it whenever operating the tractor.
*Features shown are available with all current model year tractors
Standard equipment lighting includes:
*Features shown are available with all current model year tractors
The field-installed cab offers protection from the elements and expands the versatility of 1025R Tractors to perform in all climates.
Key features:
Specifications:
Optional kits:
Compatibility and Installation:
Yanmar is a U.S.-registered trademark of Yanmar Company Limited.
One of the greatest operator concerns involves difficulty in attaching tractor implements. John Deere has addressed this issue with the iMatch Quick-Hitch.
The iMatch Quick-Hitch provides easy hookup and a guaranteed fit for all Category 1 implements that are designed to meet the ASABE Category 1 Standard S278.6 for quick-attach hitches.
NOTE: The bushing set can be seen in the picture above. These bushings allow the hooks on the iMatch and the pins on the implement to fit together properly. All other implements (box blades, tillers, rear blades, etc.) will require a set of bushings to enlarge the pin to fit with the iMatch hooks. Bushings of different lengths can be found in the parts system or through a bushing supplier (see dimensions below).
*Features shown are available with all current model year tractors.
Both 4WD and power steering are standard equipment on the 1025R. This combination allows for excellent maneuverability and ease of operation of the tractor.
Specifications | ||||
---|---|---|---|---|
Select up to 4 models to compare specifications | John Deere1025RSub-Compact Utility Tractor |
Family | EYDXL1.27NS1 FYDXL1.27NS1 GYDXL1.27NS1 | |||
---|---|---|---|---|
Manufacturer | Yanmar | |||
Engine model | 3TNV80F-NCJT | |||
Engine power (gross) | 17.8 kW 23.9 hp 24.2 PS SAE J1995 rated power | |||
Power take-off (PTO) power | 13.4 kW 18 hp | |||
Rated engine speed | 3200 rpm | |||
Type | Diesel | |||
Injection pump type | Indirect Injection | |||
Aspiration | Natural | |||
Emissions compliance | Final Tier 4 | |||
Cylinders/displacement | 3 / 1.267 L 3 / 77.3 cu in. | |||
Number of cylinders | Three | |||
Cylinder liners | Cast-in-block | |||
Bore and stroke | 80x84 mm 3.15x3.31 in. | |||
Compression ratio | 23.0:1 | |||
Lubrication | Pressurized | |||
Cooling system | Water pump | |||
Air cleaner | Dual element with mechanical restriction indicator | |||
Engine torque at rated speed | 55.2 Nm 40.7 lb-ft | |||
Fuel tank capacity | 21.2 L 5.6 U.S. gal. |
Battery size | 500 CCA | |||
---|---|---|---|---|
Alternator (12-V) | 40 amp | |||
Starter size | 1.2 kW 1.6 hp |
Type | Indirect Injection | |||
---|---|---|---|---|
Fuel consumption | 5.8 L/hr 1.5 U.S. gal./hr |
Standard transmission; forward/reverse | Hydrostatic - 2 range | |||
---|---|---|---|---|
Optional transmission; forward/reverse | ||||
Left-hand reverser | No | |||
Transmission gear ranges | ||||
Final drive | Bull Gear | |||
Brakes | Wet disc (left-hand pedal) | |||
Steering | Power | |||
Clutch, wet/dry | N/A | |||
Clutch disk diameter wet clutch | ||||
Axle capacity | Front 612 kg 1349 lbRear 715 kg 1576 lb | |||
Creeper | No | |||
Cruise control | Standard | |||
Differential lock | Yes | |||
Drawbar maximum vertical load |
Type | Open center | |||
---|---|---|---|---|
Pump rated output | Steering 10.8 L/min 2.8 gpmImplement 13.2 L/min 3.5 gpm 24 L/min 6.3 gpm | |||
Pump type | Gear | |||
Maximum operating pressure | 137.9 bar 2000 psi | |||
Draft control sensing | Position control | |||
Remote control valves available | Two |
Category | Limited Category 1 | |||
---|---|---|---|---|
Lift capacity, 24-in. behind link arms | 309 kg 681 lb |
Standard | Rear - 540 rpm Mid - 2100 rpm | |||
---|---|---|---|---|
Optional | ||||
Control | Independent | |||
Clutch | Wet disc | |||
Brake (for mid and rear PTO) | Wet disc | |||
Engagement method |
Crankcase with filter | 2.7 L 2.9 qt | |||
---|---|---|---|---|
Transmission and hydraulic system | 3.7 gal. 14 L |
Type | Bull Gear | |||
---|---|---|---|---|
Differential lock | Yes |
Rollover protective structure | Type Foldable Yes | |||
---|---|---|---|---|
Platform - flat/straddle | One-piece semi flat | |||
Gear shift location - console/floor | Left-hand side |
Compliance | NA | |||
---|---|---|---|---|
Visibility | NA | |||
Air conditioning, temperature differential | NA | |||
Doors | NA | |||
Noise rating | NA | |||
Seat equipment | NA |
Wheelbase | 145 cm 57.1 in. | |||
---|---|---|---|---|
Front axle clearance | 195 mm 7.7 in. | |||
Turning radius with brakes | ||||
Turning radius without brakes | 2.25 m 7.4 ft | |||
Limited slip differential | No | |||
Approximate shipping weight (open-station; cab) | 655 kg 1444 lb |
Front | R4 - 18x8.5-10 | |||
---|---|---|---|---|
Rear | R4 - 26x12-12 | |||
Front tread range | 91.8 cm 36.1 in. | |||
Rear tread spacing |
Toolbox | Yes | |||
---|---|---|---|---|
Tilt steering wheel | ||||
12-V Outlet |
Date collected |
---|
A ballast box can be used to carry additional ballast for greater tractor stability.
A 23-cm (9-in.) high extension can be added to ballast box for even greater capacity.
![]() |
Ballast box extension |
The hitch utilizes a standard Category 1 configuration for connection to the tractor Category 1 hitch.
A bushing kit is required for the ballast box to be used with the iMatch™ Quick-Hitch.
The ballast box can be used to carry additional ballast for greater tractor stability.
A 23-cm (9-in.) high extension can be added to ballast box for even greater capacity.
The hitch utilizes a standard Category 1 configuration for connection to the tractor Category 1 hitch.
A bushing kit is required for the ballast box to be used with the iMatch™ Quick-Hitch.
The ballast box extension is only available through Parts; it is not a factory option.
Fits into engine block to help provide faster and easier starts in extremely cold weather (below 0°F or –18°C). Uses 110-volt electricity.
Allow one hour to install.
Attached to the engine cylinder block, the engine coolant heater plugs into a 120-V electrical outlet to warm the engine for fast cold-weather starts.
NOTE: It is recommended to install optional engine coolant heater, transmission oil heater, and battery heating pad (A22400P - ordered through A and I) if operating machine in temperatures below -18 ⁰C (0⁰F).
Customers, please contact your local John Deere dealer for availability and pricing information.
iMatch Quick-Hitch Bushings
Order number: LP19969
An optional premium light kit is available to provide extra visibility when working in dark conditions. The premium light kit includes the following:
This kit provides light to the rear of the tractor for evening work.
For open-station tractors only, this kit contains individual light.
Allow 30 minutes to install.
NOTE: Kit includes one rear light.
NOTE: Both the rear- and forward-work lights are compatible together and with the light-brush guard kits. The light kit contains a two-to-four pigtail that plugs into the main harness, as if only plugging one set of lights, providing two sets of plugs to use for forward and rear-work lights. The forward light is installed on top of the brush guard, and the rear light is installed inside the ROPS using the bolt holding the light and brush guard on.
NOTE: For 102E3 and 1026R Tractors – kit interference during backhoe operations (mounted inside ROPS) – use LVB25546 forward-light kit as an alternative.
The forward-lighting kit provides extra visibility when working in dark conditions. Lights attach to the brush guards located on the rollover protective structure (ROPS). Each kit contains two lights.
NOTE: Requires BLV10400 warning light brush guard kit and LVB26026 light kit harness. Not compatible with LVB25547 rear work light kit (1023E).
NOTE: Requires BLV10400 warning light brush guard kit. Not compatible with LVB25547 rear work light kit (1025R, 2025R, 2032R, 2038R, 3025E, 3032E, 3038E, 4105, 4044M, 4052M, 4066M).
NOTE: Requires BLV10620 premium warning light brush guard kit. Not compatible with LVB25547 rear work light kit (3033R, 3039R, 3046R, 4044R, 4052R, 4066R).
Rollover protective structure (ROPS) mounted LED work lights
An optional LED work light kit is available for all open-station compact utility tractors. These lights provide extra visibility when working in dark conditions and have 180-degree rotation to face forward or backward. The kit contains two lights and the mounting hardware required for installation.
This lighting kit is mounted to the warning light brush guard kit, which is mounted to the ROPS and requires attachment BLV10400 for installation.
The halogen work light kit attachment is still available (LVB25546).
ROPS warning-light brush guards protect turn signal/warning lights from damage caused by low branches on trees.
Two guards are included in each kit and are for open-operator station (OOS) tractors only.
An optional premium light kit is available to provide extra visibility when working in dark conditions. The premium light kit includes the following:
A 55-amp alternator can be ordered as an upgrade kit to replace the standard equipment 40-amp alternator. This alternator is suited for tractors equipped with aftermarket cab enclosures and lighting kits requiring higher amperage to operate.
Filter Paks are a handy and convenient way for dealers to supply a customer with the maintenance-interval parts as specified in their operator's manual. These kits contain an oil filter, air filter, fuel filter and hydraulic filter, offering a complete solution for all your customers’ maintenance needs to keep their tractors running at peak performance.
Benefits of Filter Paks:
Easy to understand – indicates models and contents so you never have to worry about the right filters for your compact utility tractor
This bushing kit is for use with Category 1 implements (ballast box) to make them function correctly with the iMatch Quick-Hitch.
One of the greatest customer concerns involves difficulty in attaching tractor implements. John Deere has addressed this issue with the iMatch Quick-Hitch.
The iMatch Quick-Hitch provides easy hookup and a guaranteed fit for all Category 1 implements that are designed to meet the ASAE Category 1 Standard S278.6 for quick-attach hitches.
NOTE: In the picture above, you see the bushing set. These bushings allow the hooks on the iMatch and the pins on the implement to fit together properly. All other implements (box blades, tillers, rear blades, etc.) will require a set of bushings to enlarge the pin to fit with the iMatch hooks. Bushings of different lengths can be found in the parts system or through a bushing supplier (see dimensions below).
Tire chains increase traction dramatically under ice and snow conditions.
One or two 23-kg (50-lb) cast-iron weights may be installed on each rear wheel to provide extra traction and stability.
One 23-kg (50-lb) plastic-shell rear-wheel weight may be installed on each rear wheel to provide extra traction and stability.
Multiple stacking is not recommended.
Overall width of the tractor will be increased by approximately 5 cm (2 in.) when weights are installed.
Weights are packaged one per carton, with necessary hardware for installation on a wheel, in either the narrow or wide position.
70-lb (32-kg) cast-iron starter weights can be bolted to the outside of the rear wheels for ballast.
Additional 50-lb (22.7-kg) cast-iron wheel weights may be bolted to the starter weight.
NOTES:
1. For 26-in. (660-mm) tire and rim only.
2. Starter weight not for use on all-wheel-steer tractors.
3. X700 Special Edition Tractors (model year 2012 and prior) and X738, X739, and X758 Signature Series Tractors require a BM21497 wheel weight adapter ring on each rear wheel on which weights are to be installed.
NOTE: Plastic rear-wheel weight comes with necessary hardware for installation.
For 23-kg (50-lb) cast-iron wheel weights on 26x12-in. rear tyres:
NOTE: Order two sets for both sides of the tractor.
For 33-kg (72-lb) starter cast-iron wheel weight on 26x12-in. rear tyres:
NOTE: Order two sets for both sides of the tractor.
For 33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s):
NOTE: Order two sets for both sides of the tractor
NOTE: Plastic rear-wheel weight comes with necessary hardware for installation.
For 23-kg (50-lb) cast-iron wheel weights on 26x12-in. rear tyres:
NOTE: Order two sets for both sides of the tractor.
For 33-kg (72-lb) starter cast-iron wheel weight on 26x12-in. rear tyres:
NOTE: Order two sets for both sides of the tractor.
For 33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s):
NOTE: Order two sets for both sides of the tractor
NOTE: Plastic rear-wheel weight comes with necessary hardware for installation.
For 23-kg (50-lb) cast-iron wheel weights on 26x12-in. rear tyres:
NOTE: Order two sets for both sides of the tractor.
For 33-kg (72-lb) starter cast-iron wheel weight on 26x12-in. rear tyres:
NOTE: Order two sets for both sides of the tractor.
For 33-kg (72-lb) starter and 23-kg (50-lb) cast-iron weight(s):
NOTE: Order two sets for both sides of the tractor
